PROSOFT MVI69-ADM Processor Module
PROSOFT MVI69-ADM
1. Overview
The MVI69-ADM is a CompactLogix backplane-compatible module designed to provide flexible computing capabilities for industrial automation applications. It is typically used alongside other MVI69 communication modules — such as the MVI69-MNET, MVI69-HART, and MVI69-DNP — to create powerful solutions for local processing and remote communication.
____________
2. Parameters
- Model: MVI69-ADM
- Compatible Platform: CompactLogix PLC (Rockwell Automation)
- Core Function: Runs user‑developed C‑language applications
- Data Processing: Optimized for efficient ASCII data communication and algorithm protection
_____________________
3. Features
- Custom Development: Supports writing and deploying custom C‑language programs to meet diverse industrial control requirements.
- High‑Performance Communication: Accelerates custom ASCII data communication and acts as a local processing unit for communication systems.
- Algorithm Protection: Executes proprietary algorithms inside the PLC to prevent algorithm exposure and enhance system security.
- Modular Design: Compact backplane‑compatible form factor that integrates seamlessly with other MVI69 modules (Modbus, HART, DNP, etc.).
______________
4. Structure & Composition
Hardware
A CompactLogix backplane‑compliant electronic module with an integrated processing unit dedicated to running user‑developed code.
Software
Users write C‑language code using ProSoft’s development tools, compile it, and download it to the module. The MVI69-ADM is often used with other MVI69 communication modules to collect and process data.
__________________
5. Applications
- Industrial Automation: Performs real‑time data processing and decision‑making on the production line.
- Custom Protocol Conversion: Handles proprietary ASCII protocols that standard PLCs cannot easily parse.
- Proprietary Algorithm Execution: Runs encrypted or specialized control algorithms locally to protect core intellectual property.
- Communication Module Integration: Works with modules such as the MVI69‑MNET (Modbus), MVI69‑HART, and MVI69‑DNP to provide complete protocol conversion and local computing solutions.
6. Installation & Maintenance
- Installation: Follows standard CompactLogix backplane installation procedures — simply insert the module into an available slot in the PLC chassis.
- Configuration: Develop C code using ProSoft’s tools, compile it, and download it to the module. Parameters are typically configured within RSLogix or Studio 5000.
- Maintenance: The modular design allows for easy replacement and software upgrades, ensuring high reliability and stability.
————————————————————————————————————-
