Schneider TSXPSY2600

The TSXPSY2600 is a compact power supply module launched by Schneider Electric, belonging to the CX1000 series of distributed I/O controllers. Adopting PC-based control technology, it integrates a real-time operating system and industrial Ethernet communication capabilities. Specifically designed for small and medium-sized automation tasks, it enables reliable network access for distributed I/O devices.

Key Technical Specifications

• Power Supply Voltage: AC 5-265 V or DC 5-125 V
• Operating Current: 0.85 – 0.9 A
• Power Consumption: Approximately 2.5 W
• Processor Speed: 10/100 Mbps Ethernet interface
• Dimensions/Form Factor: Standard 1-slot or 2-slot rack-mounted module, compatible with Modicon TSX series bases

Product Features

• Wide Voltage Range: Supports a broad range of AC/DC inputs, suitable for various power grid environments.
• Low Power Consumption: Only 2.5 W (or 26 W) power consumption, ensuring energy efficiency and low heat generation.
• Plug-and-Play: Modular design facilitates quick on-site insertion, removal, and replacement.
• High Reliability: Complies with industrial-grade protection standards, ideal for harsh working conditions.
• Compatibility: Works seamlessly with Modicon TSX series bases and other TSX series I/O modules, enabling easy system expansion.

Structure and Composition

• Power Unit: Responsible for AC/DC conversion and voltage regulation.
• Communication Interface: 10/100 Mbps Ethernet port for communication with upper-level computers or PLC masters.
• Rack Mounting Bracket: Conforms to standard 19-inch rack dimensions, allowing direct installation into TSX bases.
• Indicators/Status Displays: Show power status, communication status, and other relevant information.

Typical Application Areas

• Distributed I/O Systems: Connect on-site sensors and actuators to industrial Ethernet.
• Small-Scale Automation Control: Local control units for packaging lines, assembly lines, etc.
• Building Automation: Power supply for building control cabinets, security modules, etc.
• Energy Management: Provide power and communication in conjunction with energy monitoring systems.

Installation Guidelines

• Rack Fixing: Slide the module into the corresponding slot of the TSX series base and ensure the buckle is securely fastened.
• Power Wiring: Connect to the appropriate terminals according to the power specifications (AC 5-265 V or DC 5-125 V) and check the polarity.
• Ethernet Connection: Use a standard RJ45 cable to connect to a network switch or PLC master.
• Indicator Check: After power-on, confirm that the power indicator is illuminated; a blinking communication indicator indicates normal operation.

Maintenance Recommendations

• Regular Inspections: Check the tightness of power terminals and wiring every 6 months to prevent loosening.
• Cleaning and Dust Prevention: Use a dry, soft cloth to remove dust from the module surface and maintain unobstructed heat dissipation channels.
• Firmware Updates: If new firmware versions are released, follow Schneider Electric’s official guidelines for updates to enhance compatibility and security.
• Spare Parts Management: It is recommended to keep a spare power module of the same model on-site for quick replacement of faulty units, minimizing downtime.
