Xycom 1500

1. Overview

2. Main Specifications

• CPU: Intel Celeron or Pentium III, up to 700 MHz
• Memory: Up to 512 MB DDR DRAM (optional)
• Storage: CompactFlash/IDE hard drive interface (depending on specific configuration)
• Network: 10/100 Mbps Ethernet interface
• Expansion Slots: 3 (PCI) or 6 (depending on model)
• Power Supply: Standard ATX power supply, power consumption less than 30 W

3. Product Features

• Highly Integrated: CPU, memory, network, and storage interfaces are integrated on a single board, featuring small size and neat wiring.
• Versatile Expansion: Equipped with up to 6 PCI expansion slots, facilitating the addition of I/O cards, communication modules, or dedicated acceleration cards.
• Reliability: Industrial-grade components support a wide temperature operating environment, suitable for continuous operation from 0 °C to 50 °C.
• Easy Maintenance: Modular design allows on-site replacement of key components, reducing maintenance downtime.
• Compatibility: Compatible with standard PC BIOS and operating systems (such as Windows 2000/XP Embedded, Linux), enabling easy software migration.

4. Structure and Composition

• Motherboard: Based on Intel Socket 370, integrated with northbridge/southbridge chipset.
• CPU Socket: Supports Celeron/PIII processors ranging from 433 MHz to 700 MHz.
• Memory Slot: Single 256 MB DDR DRAM slot, expandable up to 512 MB.
• Network Module: Integrated 10/100 Mbps Ethernet controller.
• Expansion Slots: 3–6 PCI (or compatible) slots, providing space for peripheral expansion.
• Storage Interface: IDE hard drive or CompactFlash interface, meeting different storage requirements.
• Power Interface: Standard ATX power connector, supporting redundant power supply options.

5. Typical Application Areas

• Industrial Edge Gateway: Data collection, preprocessing, and local decision-making.
• Small Server/File Storage: Lightweight file services or database front-ends.
• Embedded Control System: Monitoring and control nodes for automated production lines.
• Intelligent Transportation/Security: Video front-end processing or on-vehicle information systems.
• Scientific Research Experiment Platform: Low-power computing platform suitable for laboratory prototype verification.

6. Installation and Maintenance Guidelines

• Installation: Adopt standard 19-inch rack or desktop bracket, ensuring good chassis ventilation.
• Wiring: Use shielded Ethernet cables to avoid high-frequency interference; maintain proper routing for hard drive and power cables.
• Cooling: Equip with low-noise fans or passive heat sinks; regularly clean dust to maintain heat dissipation efficiency.
• Firmware Upgrade: Perform firmware upgrades via BIOS update tools, recommended to be completed during downtime windows.
• Troubleshooting: Use the diagnostic LEDs and POST information built into the motherboard to quickly locate hardware faults; key components (CPU, memory, PCI cards) can be replaced individually for verification.

————————————————————————————————————-
