Xycom 3112T

Xycom 3112T is a high-resolution touch operation station designed for industrial automation sites. It features a 12.1-inch SVGA (800 × 600) color LCD, paired with a 1.2 GHz Celeron processor and 256 MB/512 MB RAM, along with 20 GB HDD storage. The device supports Windows XP/2000 operating systems or can run as a bare-bones system without an OS. Positioned as a compact and reliable on-site operation terminal, it is ideal for control scenarios requiring fast response and intuitive interaction.

Key Technical Specifications

• Display: 12.1-inch SVGA (800 × 600) touch LCD with cutout mounting, measuring approximately 314.3 mm × 231.9 mm × 99 mm.
• CPU: Intel Celeron 1.2 GHz
• Memory: 256 MB or 512 MB DDR; some configurations can be upgraded to 1 GB.
• Storage: 20 GB mechanical hard drive (SSD/CF card optional).
• Operating System: Compatible with Windows XP and Windows 2000; also usable as a bare-bones system without an OS.
• Interfaces: 2 × USB 1.1, serial port, parallel port, VGA, audio, keyboard/mouse ports. Supports industrial communications including RS-485 and Ethernet (10/100 Mbps).
• Power Supply: 24 V DC (operating voltage range: 18-30 V), IP65 protection rating, operating temperature range: -20 °C to 60 °C.
• Dimensions/Weight: Approximately 314 mm × 232 mm × 99 mm, weight around 5 kg (varies by configuration).

Product Features

• High Reliability: Industrial-grade protection (IP65) and wide operating temperature range enable adaptation to harsh on-site environments.
• Fast Response: The 1.2 GHz processor combined with 256 MB RAM ensures smooth operation of common PLC/HMI software and upper monitoring systems such as WinCC, Pro-Face, and iFIX.
• Flexible Installation: Supports cutout mounting with a compact design, facilitating embedding in cabinets or control boxes.
• Multi-interface Compatibility: Equipped with rich industrial communication ports, it can directly connect to fieldbuses or Ethernet for seamless integration with PLCs, robots, and servo systems.
• Easy Maintenance: Modular design supports hot-swappable replacement, reducing downtime for maintenance.

Structure and Components

• Display Module: Touch LCD and backlight system.
• Main Control Board: CPU, memory, storage, and I/O expansion interfaces.
• Power Supply Module: 24 V DC regulated power supply with overvoltage and overcurrent protection.
• Communication Cards: Industrial communication interface cards for RS-485, Ethernet, parallel port, etc.
• Chassis/Panel: Metal or plastic housing with dustproof and waterproof gaskets.

Typical Application Fields

• Industrial Automation Control Stations: Works with XYCOM products, PLCs, robots, and servo systems to enable on-site parameter setting, fault diagnosis, and real-time monitoring.
• Manufacturing Production Lines: Used for machine debugging, process parameter input, and production line status display.
• Heavy Industries (Energy, Petrochemical, Metallurgy, etc.): Provides reliable human-machine interaction in high-temperature, humid, or dusty environments.
• Logistics and Warehousing Systems: Facilitates equipment status monitoring, manual intervention, and command issuance.

Installation and Maintenance Guidelines

• Power Off Operation: Ensure the host power is turned off before installation to prevent electrostatic discharge from damaging the main control board.
• Panel Disassembly/Assembly: Record the positions of screws before removing the original keyboard or panel to avoid incorrect reinstallation.
• Slot Alignment: Align the Xycom 3112T keyboard or module with the corresponding slot. Secure the screws only after confirming the cable connector is fully inserted.
• Seal Inspection: After reinstalling the panel, check that the gasket is intact to maintain the IP65 protection rating.
• Function Verification: After powering on, check that the touchscreen responds properly, the display functions normally, and all communication port signals are intact. Perform a system self-test if necessary.
• Regular Maintenance: Clean dust from the panel and check for blocked heat sinks to ensure smooth heat dissipation and extend service life.
