XYCOM 3115T LCD

Overview

Key Specifications

• Screen Size: 15.0 inches (approximately 306 mm × 218 mm)
• Resolution: 1920 × 1200 (RGB)
• Contrast Ratio: Approximately 1500:1
• Color Gamut: Approximately 45% (sRGB)
• Brightness/Backlight: External backlight module required, typically equipped with LED backlight of 200 cd/m² or higher
• Viewing Angle: Approximately 160° horizontally/vertically
• Operating Temperature: -20 °C ~ +60 °C (Industrial Grade)
• Protection Level: IP65 (Dustproof and Waterproof)
• Interfaces: LVDS/eDP video interfaces, backlight power supply interface, optional DVI/HDMI adapter

Product Features

• Modular Design: The LCD panel is separated from the backlight, facilitating on-site backlight replacement or upgrade and improving maintenance convenience.
• Industrial-Grade Reliability: Adopts a high-strength metal frame, IP65 protection, and a wide operating temperature range to adapt to harsh on-site environments.
• Touch Compatibility: Optional Dynapro touch layer supports 10-point capacitive touch, meeting human-machine interaction needs.
• Low Power Consumption: Uses a low-power driver IC, controlling the overall power consumption below 30 W to reduce heat dissipation pressure.
• Multiple Interfaces: Compatible with various video signals such as LVDS, eDP, and HDMI, enabling easy connection with different motherboards or controllers.

Structure and Composition

• LCD Layer: Provides optical display functionality.
• TFT Glass Substrate: Drives the switching of each pixel.
• Color Filter (CF): Implements color separation.
• Polarizer: Controls the polarization direction of light.
• Driver IC: Responsible for pixel voltage control.
• COF (Chip-on-Film): Flexible circuit connecting the driver IC and TFT glass.
• External Backlight Module: LED backlight unit that provides uniform light source.

Typical Application Fields

• Industrial Automation Control Stations: Such as PLC/HMI panels and CNC machine tool operation interfaces.
• Logistics and Warehousing: Barcode/QR code scanning terminals and warehouse management systems.
• Medical Equipment: Operating room information displays and diagnosis and treatment workstations.
• Transportation: On-board information displays and railway dispatching terminals.
• Retail Self-Service Terminals: Self-ordering machines, vending machines, and information inquiry screens.

Installation Methods

• Panel Installation: Fix to the metal frame using screws or buckles, enabling wall-mounted, desktop, or cabinet-embedded installation.
• Backlight Matching: Connect the backlight unit to the LCD panel via a dedicated backlight connection cable to ensure uniform light source coverage.
• Cable Routing: Use protective trunking to connect LVDS/eDP video cables and backlight power cables to the host, keeping cables organized and preventing interference.
• Protective Sealing: In IP65 environments, use waterproof rubber rings or sealing strips to close the gap between the panel and the chassis.

Maintenance Points

• Regular Cleaning: Use a soft, lint-free dry cloth or special screen cleaner to avoid scratching the polarizer.
• Backlight Inspection: Check the brightness attenuation of backlight LEDs every 12 months and replace the backlight module if necessary.
• Connection Inspection: Ensure LVDS/eDP interfaces and backlight power cables are free of looseness and corrosion to prevent signal loss or screen flicker.
• Dust and Moisture Prevention: In high-dust or humid environments, it is recommended to install dust filters or use moisture-proof packaging for storage.
• Firmware Upgrade: If the LCD driver IC supports firmware updates, regularly check for upgrade packages released by the manufacturer to improve compatibility and stability.

————————————————————————————————————-
