XYCOM GP577R-TC11 Human-Machine Interface
XYCOM GP577R-TC11
1. Overview
Xycom 3715 KPMT is a high-end model in the KPM (Keyboard-Panel-Monitor) series, an all-in-one industrial PC integrating CPU, display, keyboard, and touch functionality. It features a 15-inch TFT LCD, supports 100-240V wide voltage input, and is equipped with a power module with a rated current of 5A, enabling long-term reliable operation in harsh industrial environments.
2. Key Technical Specifications
| Parameter | Typical Value |
|---|---|
| Display | 15-inch TFT LCD, resolution 800×600 (SVGA), optional XGA 1024×768 |
| Touch Method | Capacitive or resistive multi-touch |
| CPU | Optional Intel Pentium III 1.0 GHz (standard), up to 1.26 GHz |
| Memory | 256 MB DDR (standard), expandable to 512 MB or higher |
| Storage | 2.5-inch IDE/HDD, SSD option available |
| Power Supply | 100-240V AC, 5A rated, built-in power module |
| Interfaces | USB 2.0 × 2, RS-232 serial port, LPT parallel port, VGA, keyboard, mouse, expandable PCI/PC/AT cards |
| Operating Temperature | -10°C ~ +55°C (optional cooling fan available) |
| Protection Class | IP54 (dust and drip proof) |
| Dimensions/Weight | Approximately 380 mm × 300 mm × 80 mm, weight about 6 kg |
3. Product Features
- All-in-One Design: Integrates CPU, display, keyboard, and touch panel into a single chassis, saving space and simplifying wiring.
- Wide Voltage Adaptability: 100-240V globally compatible power supply, suitable for cross-border projects.
- High Reliability: IP54 protection, industrial-grade components, anti-electromagnetic interference, and compliance with IEC 60730-1 safety standards.
- Maintainability: Modular power supply, display, and touch layer can be replaced individually, reducing maintenance costs; supports BIOS/driver OTA upgrade.
- Rich Interfaces: Compatible with multiple field buses and industrial networks (RS-232/485, Ethernet, USB) of traditional PLC and SCADA systems.
- Software Ecosystem: Comes with OpenHMI and Pro-Face Runtime, supports Windows XP/7/10 Embedded, facilitating secondary development.
4. Structure and Composition
- Chassis: Metal frame with internal shockproof gaskets.
- Power Module: Internal 5A AC power supply with overvoltage, undervoltage, and short-circuit protection.
- Motherboard: Integrates CPU, northbridge/southbridge, memory slots, and PCI/PC/AT expansion slots.
- Display Module: 15-inch TFT LCD with LED backlight, supporting brightness adjustment.
- Touch Layer: Capacitive/resistive touch sensor layer with calibration software.
- Keyboard/Keys: Waterproof and dustproof industrial keyboard with customizable key positions.
- Interface Panel: USB, serial port, parallel port, VGA, audio, and other interfaces arranged on the front and rear panels respectively.
- Heat Dissipation System: Passive heat sink + optional fan to ensure thermal balance in high-temperature environments.
5. Typical Application Fields
| Industry | Specific Scenarios |
|---|---|
| Automated Production Lines | Machine vision, PLC HMI, process parameter monitoring |
| Logistics and Warehousing | Goods sorting systems, AGV control panels, warehouse management terminals |
| Energy and Power | Power distribution automation, substation monitoring, generator set control |
| Transportation | Rail transit signals, vehicle scheduling, station information display |
| Petrochemical and Metallurgy | Process control, hazardous area monitoring, on-site data collection |
| Building Facility Management | HVAC control, building automation, security monitoring |
6. Installation and Maintenance Guidelines
- On-Site Inspection
- Confirm that the operating environment temperature and humidity are within the specified range.
- Check that the chassis installation location has sufficient heat dissipation space (≥30mm ventilation gap).
- Power Connection
- Use power cables complying with IEC 60320-C13/C14 standards to ensure good grounding (grounding resistance ≤1Ω).
- Internal Hardware Replacement
- The display module, touch layer, and power module are all detachable with a snap-on design. They can be replaced individually in case of failure without returning the entire unit for repair.
- Firmware/Driver Upgrade
- Check BIOS and driver versions through OpenHMI software. It is recommended to check and upgrade every 6 months to obtain the latest security patches.
- Cleaning and Maintenance
- Wipe the screen with a soft lint-free cloth dipped in a small amount of neutral detergent. Avoid alcohol or strong acids and alkalis.
- Regularly clean dust on the heat sink to prevent poor heat dissipation.
- Troubleshooting
- Quickly locate faults through the front-panel LED indicators (power, system, network).
- For in-depth diagnosis, use the Pro-Face Diagnostic Tool to read system logs.
- Spare Parts Management
- It is recommended to keep spare parts for the three key components: power module, display module, and touch layer, to shorten maintenance downtime.
————————————————————————————————————-
