XYCOM XVME-010

The XVME‑010 is a module under the SRM (System Resource Module) series by XYCOM. It adopts a VME‑bus architecture and is mainly used in industrial control systems to provide general-purpose I/O, counting, or intermediate layer functions. This module comes in a PCB form, is compatible with standard VME‑bus slots, and can be used in combination with other VME‑cards inside a chassis to form a modular and scalable control platform.

Main Technical Specifications

• Model/Part Number: XVME‑010 (PN: 70010‑001)
• Power Supply: 24 V DC (compliant with IEC 61131‑3 standard)
• Operating Temperature Range: ‑10 ℃ ~ +60 ℃
• Communication Interfaces: Supports industrial protocols such as Modbus and Ethernet/IP
• I/O Configuration: Provides digital input/output and analog channels (the specific number of channels varies by sub-model)
• Dimensions: Compliant with VME‑bus standard card size (6U height)

Product Features

• Modular Design: Can be flexibly inserted into and removed from the VME‑bus system, facilitating system expansion and maintenance.
• Multi-Protocol Compatibility: Built-in Modbus and Ethernet/IP, enabling easy data interaction with upper computers or PLCs.
• Industrial-Grade Reliability: Features a wide operating temperature range and strong anti-interference capability, making it suitable for harsh industrial environments.
• Compliance with IEC 61131‑3: Supports standardized programming languages, facilitating secondary development and debugging.

Structure and Composition

• PCB Main Board: The core circuit board that integrates power management, I/O interfaces, communication chips, and other components.
• Slot Interface: A standard VME‑bus slot used for connecting to the chassis backplane.
• I/O Interface Pin Headers: Provide terminals for input and output of digital and analog signals.
• Communication Module: Includes Ethernet ports, RS‑485/RS‑232 interfaces, etc.

Typical Application Areas

• Process control and monitoring in automated production lines
• Motion control in machine tools and numerical control systems
• Energy management (e.g., power distribution automation)
• Equipment linkage in logistics and warehousing systems
• Any on-site control scenarios that require reliable I/O and industrial network communication

Installation and Maintenance Guidelines

Installation

1. Insert the XVME‑010 into a chassis slot that complies with the VME‑bus standard, ensuring the back of the card is aligned with the backplane latches.
2. Connect the power cable (24 V DC) and signal cables, and check that the wiring direction is consistent with the markings.
3. Conduct a power check before startup to ensure there is no short circuit or abnormal voltage.

Debugging

1. Read the module status through upper computer or PLC software to verify that the I/O channels and communication interfaces are functioning properly.
2. Use Modbus/Ethernet testing tools to check network connectivity.

Daily Maintenance

1. Regularly check the tightness of power and signal wiring connections to prevent signal failure caused by loose connections.
2. Clean the dust on the surface of the card to keep the heat dissipation channels unobstructed.
3. In case of a fault, first check the power supply and communication cables, then locate the faulty component through software logs.

————————————————————————————————————-
