Eaton FDE316035 Filter Element
Eaton FDE316035
1. Overview
Product Positioning: Eaton FDE316035 is a hydraulic oil filter element designed to remove solid particles, metal chips, and moisture from oil circuits. It protects hydraulic pumps, valves, and actuators.Application Scope: Suitable for scenarios requiring reliable hydraulic systems, including industrial machinery, mobile equipment, marine vessels, and mining operations.
2. Key Specifications
| Specification | Details |
|---|---|
| Filtration Precision | Multiple options available: 1 µm, 3 µm, 5 µm, 10 µm, 20 µm, 25 µm, 40 µm, 50 µm, 80 µm, 100 µm, 150 µm, 200 µm |
| Filter Media | Glass fiber, filter paper, or stainless steel mesh |
| End Cap Material | Carbon steel, stainless steel, aluminum, nylon, NBS |
| Operating Temperature Range | –4 °F ~ 212 °F (approximately –20 °C ~ 100 °C) |
| Size/Connection | Compatible with standard flanges of the FDE‑3xxx series. Specific flange dimensions are indicated in the product catalog. |
| Rated Flow | Dependent on filter element area and media pore size. Typically ranges from 10 – 150 L/min, with actual values varying by specific model. |
3. Product Features
- High Reliability: Uses Eaton original filter media to ensure long-term performance without failure.
- Multi-stage Filtration: Combines filter elements of different pore sizes for primary and fine filtration, enhancing system cleanliness.
- Temperature and Pressure Resistance: Diversified end cap materials meet the requirements of high-temperature oil circuits or high-pressure environments.
- Easy Replacement Design: Standard flange connection enables quick on-site assembly and disassembly, reducing maintenance downtime.
4. Structure and Composition
- Filter Element Body: Wound or folded from the selected filter media (glass fiber/filter paper/metal mesh).
- End Caps: Metal or composite material caps at both ends provide sealing and connect to flanges.
- Sealing Gaskets: Usually made of rubber or polytetrafluoroethylene (PTFE) to prevent leakage.
- Support Frame (Optional): Metal support frame used in high-pressure applications to avoid filter element deformation.
5. Typical Application Fields
- Industrial Hydraulic Systems: Such as stamping machines, injection molding machines, die-casting machines, etc.
- Mobile Machinery: Construction machinery, mining equipment, agricultural machinery.
- Marine and Offshore Platforms: Ship propulsion systems, hydraulic circuits of offshore drilling platforms.
- Energy and Power Generation: Hydraulic drives for wind power and photovoltaic tracking systems.
6. Installation and Maintenance Guidelines
Selection
Choose the appropriate pore size and end cap material based on the system’s operating pressure, flow rate, oil temperature, and required filtration precision.
Installation
- Ensure the flange surface is clean and free of damage.
- Use the sealing gaskets recommended by the original factory. Tighten bolts in an even, cross torque sequence.
Inspection Cycle
- Regularly check the filtration pressure drop. Replace when the pressure drop exceeds 20% of the rated value.
- For high-contamination environments, replacement is recommended every 3,000 – 5,000 hours. For clean systems, the interval can be extended to 10,000 hours.
Replacement
- Always shut down the system and drain residual oil before replacement to prevent oil splashing.
- Flush the system after replacement to ensure no foreign matter remains.
————————————————————————————————————-
