GE DS3820PSCC1D1B

GE DS3820PSCC1D1B is a power supply module/analog I/O card manufactured by General Electric (GE). It is commonly used in industrial automation control systems, PLCs, PACs, as well as power distribution and unit control scenarios. The module provides stable DC power output, is compatible with multiple control platforms, and supports voltage levels such as 24 VDC, 5 V, and ±15 V.

Key Specifications

• Input Voltage: 90-132 VAC or 180-264 VAC
• Output Voltage: +5 V 20 A, +15 V 2 A, -15 V 2 A; Power: approx. 120 W; Efficiency: > 80%
• Ripple/Noise: +5 V < 2 mVrms, ±15 V < 1 mVrms
• Operating Temperature: -40 °C to +85 °C
• Protection Functions: Overvoltage, overcurrent, short circuit, overtemperature, and other multiple protections
• Dimensions/Weight: approx. 120 mm × 70 mm × 40 mm; Weight: approx. 0.5 kg
• Installation Method: DIN rail or panel quick screw mounting, equipped with quick-connect terminals

Product Features

• High Reliability: Adopts industrial-grade components, resistant to high temperature and interference, suitable for harsh on-site environments.
• Low Noise & Low Ripple: Extremely low output voltage ripple, meeting the power quality requirements of precision control systems.
• Multiple Protections: Built-in overvoltage, overcurrent, short circuit, and overtemperature protection to improve system safety.
• Modular Design: Small size and light weight, facilitating flexible layout in the cabinet.
• Strong Compatibility: Can be directly used in GE RX3i, GE Fanuc, and other PLC/PAC systems, supporting 24 VDC control signal input.

Structure and Composition

• Power Conversion Unit: Implements AC-DC and DC-DC conversion, providing multiple regulated outputs.
• Protection Circuit: Includes overvoltage, overcurrent, short circuit, and overtemperature detection modules.
• Interface Terminals: High-current terminals, low-voltage terminals, and signal input terminals, all using screw or quick snap-on connections.
• Heat Dissipation Structure: Metal housing combined with internal heat sinks ensures thermal management during long-term operation.

Typical Application Fields

• Industrial Automation: Power supply for PLCs, PACs, and CNC systems.
• Unit and Turbine Control: Provides regulated power supply for turbines and generator sets.
• Robotics and Motion Control: Power supply for drives and servo systems.
• Power Distribution and Monitoring: Auxiliary power supply for distribution cabinets and monitoring systems.
• Other Scenarios Requiring Low-Noise DC Power: Such as sensor arrays and communication modules.

Installation and Maintenance Guidelines

• Location Selection: Ensure the installation position has good ventilation, avoiding high temperature or strong magnetic field interference.
• Power Wiring: First confirm the input voltage range (90-132 VAC or 180-264 VAC), and use cables and terminals that meet specifications.
• Fixing Method: Adopt DIN rail or panel quick screw mounting to ensure the module is firmly fixed without shaking.
• Protection Function Check: Check if overvoltage, overcurrent, and short circuit protection work normally before power-on.
• Regular Inspection: Inspect terminal tightness, heat sink dust accumulation, and whether the housing has cracks or corrosion every 6-12 months.
• Replacement and Maintenance: If abnormal noise, overtemperature alarm, or unstable output occurs, first cut off the power to check the internal fuse or protection circuit, and replace the entire unit or corresponding sub-module if necessary.

————————————————————————————————————-
